Machines & equipment for sale

Cemastir Lavametalli S.r.l ATR450/2 Multi Stage Aqueous Cleaning and Drying Machine

Used / Second Hand

Refurbished Price [?]
£ Login or Register for price
Availability
Available for immediate collection
Condition
Brand New, Excellent Condition, Ex demonstration, Unused, Current Model
Buy Now Add to Quote Contact Us
Stock No
DF1638J
Manufacturer
Cemastir Lavametalli S.r.l
Model
ATR 450/2
Year of Manufacture
2024
Serial
M.149.24001
Condition
Brand New, Excellent Condition, Ex demonstration, Unused, Current Model
Work Envelope (WxDxH mm) [?]
450 x 300 x 200mm
Process Stages
2 Tank - Wash & Rinse - Both 250L
Other Info
Max Load 200kg
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
1500
External Dimensions (WxDxH mm) [?]
1520 x 2130 x 2140
Delivery
Your delivery options

Description

This ex-demo rotating drum industrial washer offers a modern, efficient solution for heavy-duty cleaning. Designed to clean components made from a variety of materials like steel, stainless steel, brass & aluminium - it delivers exceptional results with a like-new performance. A rare opportunity to invest in high-quality industrial washing for a fraction of the price new.

Suitable for components such as blind holes, recesses, small metal parts, valves etc.

Cleaning Features

The washing basket rotates on its longitudinal axis both clockwise and anticlockwise, thus ensuring a perfect washing result. Ending every cleaning cycle by automatically aligning the basket to the exit of unloading. For precision cleaning, the opposite ramp rotation angles the basket so it facing opposite the spray ramp for optimum cleaning results.

Constructed of stainless steel, this ATR cleaner can be used for cleaning components via spraying, immersion or both using the two tanks.

The ATR model is mechanically pre-set for the most important options required: oil skimmer for each tanks, hot air drying, vertical filters, ultrasonic and steam condenser.

Specifications

  • Basket size: 450mm x 300mm x 200mm
  • Max load: 200kg
  • Wash tank: 250 litres
  • Rinse tank: 250 litres
  • Machine weight: 1500kg
  • Machine size (WxDxH): 1520mm x  2130mm x 2140mm
  • Basket load height - 1080mm
  • Washing flow & pressure: 125 litres / min & 4.5 BAR
  • Rinsing flow & pressure: 125 litres / min & 4.5 BAR
  • Tanks temperature (min/max): 20 - 90°C
  • Washing heating elements: 12kW
  • Rinsing heating elements: 8kW
  • Basket rotation: 0.18kw  /  0.8-2.3 RPM
  • Spraying ramps rotation: 0.09kw - 2.3 RPM
  • Compressed air - 6 bar

 Cleaning Cycle Options Available

  • Washing
  • Washing & immersion with turbulence
  • Wash, rinse & immersion with turbulence
  • Wash, rinse & ultrasonic immersion
  • Hot air & vacuum drying

pdf icon Print / Download Cemastir Lavametalli S.r.l ATR450/2 Multi Stage Aqueous Cleaning and Drying Machine Datasheet

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
