Hedinair Electric Stand Mounted Air Circulated Treatments Oven

- Stock No
- OA2170
- Manufacturer
- Hedinair
- Model
- 18149
- Condition
- From a working environment, Good Condition
- Internal Size (WxDxH mm) [?]
- 600 x 680 x 560
- Max Temp
- 200°c
- Other Info
- 4.6kW 1ph 19.7amp
- Location
- Rolls Royce stores, near Derby, UK
- External Dimensions (WxDxH mm) [?]
- 900 x 1180 x 1740
Description
Hedinair Electric Stand Mounted Air Circulated Treatments Oven
A second hand Hedinair Hotline Oven - This Electric Small Capacity Batch Oven is suitable
for all types of production work including heavy loads.
Ideal for varnish baking, paint stoving, rubber curing, resin bonding, and mould pre-heating.
Former Rolls Royce MachineryThis plant is one of several machines acquired during Rolls Royce's reorganisation of their manufacturing facility at Inchinnan, UK.
|
.
- The Control panel is roof-mounted for space-saving, with simple red/green on/off buttons and set and display temp controller
- Maximum Temp - 200 Degree Celsius
- Eurotherm 2216 & 2132i controlling operating temperature and over-temperature functions
- Chessell chart recorder with on/off duty switch
- 4KW (Kilowatts) of split load heaters installed
- Rear Mounted fan for even hot air distribution within the heating chamber during processing.
- Single robustly constructed locking door.
- Stand mounted
Ideally suited to low-temperature thermal treatments such as stress relieving, de-embrittling, tempering.
Alternative applications being the pre-heating of ferrous/non-ferrous/plastic/wood/glass substrates or curing/stoving suitable coatings.
This would make an excellent addition for those processing small batches/sample runs in a production or laboratory environment.
Electrical information
240v / 1ph / 50Hz / 4kw / 18A
Print / Download Hedinair Electric Stand Mounted Air Circulated Treatments Oven Datasheet
Additional files
Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
