Machines & equipment for sale

Nuair Mini Single Phase Air Compressor

Used / Second Hand

Refurbished Price [?]
£ Login or Register for price
Availability:
In stock now
Condition
From a working environment, Excellent Condition, Current Model
Stock No
AZ192
Manufacturer
Nuair
Model
B3800B/150 FM3 UK
Year of Manufacture
2014
Serial
36HN504FPS012
Condition
From a working environment, Excellent Condition, Current Model
CFM/Kw
13.8 / 2.2kW
Compressor Type
Reciprocating
Other Info
Tank Mounted
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
96kg
External Dimensions (WxDxH mm) [?]
1310x430x1090

Description

The Nuair NB38C/150 FM3 is a stationary workshop compressor packed with quality and features, typical of the brand. The extra-large capacity tank makes for a displacement capacity of 395 litres / per minute at a working pressure of 10 bar / 145 PSI.

Fitted with a B38B single-stage compressor pump unit, automatic eco stop/start, and advanced air cooling system, this compressor is perfect for commercial applications. The 3HP, 2.2kW electrical motor is overload protected.

1/2" BSP male thread on the output pipe.

Specification

<th class="label">Part Number</th><th class="label">Product Weight</th><th class="label">Outlet size</th><th class="label">Brand</th><th class="label">Tank Size</th><th class="label">Air Displacement (CFM)</th><th class="label">Sound Level @ 7m</th><th class="label">Motor Power</th><th class="label">Engine HP</th><th class="label">Power Source</th><th class="label">Voltage</th><th class="label">Discharge Pressure</th>
S-36HN504FPS012
96
 1/2" BSP
Nuair
150 Litres
10 to 15 CFM
97 dB
2.2 kW
3.0 HP
Electric
230V
145 PSI / 10 bar



pdf icon Print / Download Nuair Mini Single Phase Air Compressor Datasheet

Additional files

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
