Machines & equipment for sale

Ellesco 900mm wide 2/3 Head, Through feed Flatbed Grindingmaster 3000

Stock No
PZ1127J
Manufacturer
Ellesco
Model
MCSB/BL 900
Year of Manufacture
1995
Serial
TM1443-07
Condition
Current Model
Other Info
Will be run and seen powered by Ellesco.
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
2850
External Dimensions (WxDxH mm) [?]
1780 x 2580 x 1920

Description

Ellesco Grindingmaster MCSB/BL 900

Selling in partnership with the OEM, Ellesco.

The MCSB 900 series can be configured for metal finishing or deburring at an affordable price, built with many quality features that competitors only ever offer as options.

The Ellesco Grindingmaster is a premier industrial metal working multi finishing machine.The MCSB 900 is a 900mm wide belt dry working Grindingmaster that is equipped with a powerful motor allowing it to process the toughest and heaviest jobs around.

Typical process applications covered by this machine:

  • Stock removal of multiple individual parts and sheet materials
  • Sizing and finishing of parts and sheet materials
  • Deburring punched, nibbled, sheared or laser-cut sheet metal parts.
  • Calibrating or keying carbon, rubber, wood or other soft materials.
  • Grain finishing of any material.


Standard features include:

  • Centralised operator control panel.
  • Full 900mm working width
  • Wide belt head with fine adjustments of contact roll, 150mm overall clearance.
  • Conveyor bed on 4 heavy duty precision spindles,
  • 4 x ridged, precision made, rubber coated, workpiece hold down rolls.
  • Motorised, single point thickness setting.
  • table brushing attachment
  • Vernier thickness read-out.
  • Conveyor reverse for set-up.
  • Variable speed table motor.
  • Fixed/floating conveyor table
  • Dust extraction funnel
  • Load amp indicator
  • Belt oscillation
  • Front edge safety bump E stop
  • Pneumatic tensioning
  • Air actuated braking


Available to purchase separately from our dust control section, you will be able to find a suitable dust control plant to match your particular process application whether it be wet or dry



Ellesco - Machinery Solutions

pdf icon Print / Download Ellesco 900mm wide 2/3 Head, Through feed Flatbed Grindingmaster 3000 Datasheet

Additional files

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
