Machines & equipment for sale

Spencer Halstead CMP8896 TD3P Dust Extractor

Used / Second Hand

Price
Please call on +44 (0) 1922 45 8000
Availability:
In stock now
Condition
From a working environment, Good Condition
Stock No
EZ1753R
Manufacturer
Spencer Halstead
Model
CMP8896 TD3P
Year of Manufacture
1988
Serial
W98291
Condition
From a working environment, Good Condition
Approx Duty CFM / M³/Hr
1500 // 2500
Filter Area ft² / m²
300 // 30
Other Info
Designed to be used with abrasive dusts
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
650 kgs
External Dimensions (WxDxH mm)
1950 x 900 x 3100 mm

Description

Spencer Halstead cartridge dust collector

Suitable for many different applications that generate light to medium volumes of any dust

The Spencer Halstead reverse jet tubular cartridge filter was developed for continuous operation in industrial process filtration and abrasive dust collection applications

Key features

  • Cartridge filter elements
  • Robust weatherproof fully welded steel construction
  • Secondary fine filters fitted
  • 4.0kW (5hp) high pressure
  • ATEX compliant features for St1, St2 and St3 dusts
  • Integral pre-separation chamber, cross flow / down flow inlet air pattern
  • Magnehelic filter monitor gauge

Typical dust control and process applications

  • Materials handling – conveying, screening, sieving, mixing, bin/silo venting
  • Shot, sand and bead blasting
  • Building materials manufacture and distribution
  • Dust extraction for all dry free flowing powders and granular material
  • Welding and cutting processes
  • Chemical, plastics and pharmaceutical powders

pdf icon Print / Download Spencer Halstead CMP8896 TD3P Dust Extractor Datasheet

Additional files

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
