Machines & equipment for sale

SAT Heavy duty electric air circulated industrial oven

Used / Second Hand

Refurbished Price [?]
£ Login or Register for price
Sold As Seen Price [?]
£ Login or Register for price
Availability:
In stock now
Condition
Good Condition, Current Model
Stock No
OX1938
Manufacturer
SAT
Year of Manufacture
2005
Serial
B1692
New or Used
Used (Second Hand)
Internal Size (WxDxH mm)
1420 x 1720 x 1770
Max Temp
180° C
Other Info
Twin air circulations fans
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
900
External Dimensions (WxDxH mm)
2640 x 2010 x 2120

Description

A second hand SAT Thermiquie, France's leading supplier of quality ovens and furnace - Electric Batch Oven which is suitable for almost any application from simple drying processes to exacting metal treatments

Sat standard Electric, forced air convection Batch Ovens are suitable for almost any application from simple drying processes to exacting
metal treatments and all types of production work including heavy work loads.

An internal shelf is designed to accommodate two batches of products, stacked vertically, so minimizing the footprint of the oven.
Ideal for varnish baking, paint stoving, rubber curing, resin bonding and mould heating.and drum warming processes

General oven specifications:-

  • Digital control instruments.
  • Horizontal twin air recirculation fans for even temperature uniformity.
  • Front loading swing aside doors
  •  Usable internal dimension of 1420 X 1720 X 1770 mm
  • 24 kW Heater loading
  • External dimensions of 2640 x 2010 x 2120 mm
  • Air inlet and outlet for passive  ventilation of heated chamber.
  • 415 Volt 36 Amp supply'

pdf icon Print / Download SAT Heavy duty electric air circulated industrial oven Datasheet

Additional files

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
