Machines & equipment for sale

Donaldson Torit (DCE) High specification revers pulse dust control plant.

Stock No
EX1669J
Manufacturer
Donaldson Torit (DCE)
Model
DFPRO 8 SPRK-R
Year of Manufacture
2006
Serial
57100374
New or Used
Used (Second Hand)
Approx Duty CFM / M³/Hr
1765 - 4708 // 3000 - 8000
Filter Area ft² / m²
292 // 141.2 m2
Other Info
Atex explosion panel R = Reinforced
Location
Our Central Warehouse, Aldridge, UK
Weight (kgs)
1375
External Dimensions (WxDxH mm)
1500 x 2080 x 3470

Description

Donaldson Torit DFPRO 8 SPRK-R

Industrial companies produce contaminants such as dust, fume or oil mist. These contaminants can interfere with production, affect the health of workers and pollute the environment. A reliable collector for improving the air quality is therefore mandatory.

Powerful Dust Collection Technology

The dust collectors of the DFPRO series set a higher standard in comparison to conventional dust removal systems in terms of filtration efficiency and are ideal for various applications, including abrasive polishing, fettling, plasma, autogenous and laser cutting.

Donaldson has improved the performance of the systems by rethinking the cartridge cross section from the conventional round to an oval shape.

The oval-shaped filter cartridges provide a more efficient, compact and economical filtration.

Main features:

  • Flow rate 8,000 m³/h
  • “Plug and Go” unit
  • Closed coverage type (complete system) and quiet operation
  • High performance oval-shaped cartridge filters and efficient filter media
  • Fast and easy installation, easy maintenance with quick-access filters
  • Energy cost saving due to low energy requirements

The DFPRO oval-shaped filters, in conjunction with our innovative nanofiber filter media, trap more dust on the surface of the filter than conventional commodity types of filter media such as depth-loading cellulose, polyester or cellulose/polyester blend.

Oval-shaped filters handle up to 25 percent more airflow than traditional circular-shaped filters without increasing velocities to ensure efficient dust control.

DFPRO Cartridge Dust Collectors Features and Advantages

  • Low pressure drop spark trap
  • Fully integrated system with damper valve, factory prewired, self-contained cleaning mechanism with automatic Torit control board
  • “Plug and Go” unit
  • No extra duct work between unit and fan
  • Cleaning mechanism protected from external elements
  • Self-centering with a handle for easy changes
  • Corner installation possible
  • Quick-release dust disposal system
  • Removable side profiles to allow fork lift transport
  • Flat side walls
  • Outside installation possible

pdf icon Print / Download Donaldson Torit (DCE) High specification revers pulse dust control plant. Datasheet

Additional files

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
