Furnace Services Limited Lead melting pot - gas fired

Direct From Site Clearance

Direct Site Clearance Price [?]
£ 9,750 (+ VAT)
Clearance ends
31 January 2019 13:00 GMT while stocks last
Buyer's Premium [?]
10% BP will be added to your invoice
Part of a Direct Site Clearance
Webster & Horsfall
Condition
From a working environment
Location
Birmingham, UK
Stock No
WEB499
Manufacturer
Furnace Services Limited
New or Used
Used (Second Hand)
Other Info
To enable molten lead coating of product
Location
Birmingham, UK

Description

Lead Bath Furnace, bath will be fabricated from 20 mm sidewalls and 25 mm base mild steel plate; the furnace case will be manufactured from 6mm mild steel plate and form sections, Furnace insulation will be graded refractory brick

 Burners and gas control system for Furnace

  • Two BIO 80 HD gas burners
  • Two BCU 370 Flame control unit
  • Two VDM gas trains
  • One gas and air pressure switch
  • One 2.2kw side channel air blower
  • Plus all pipe work and fittings

 Control

  • One West controller
  • One West policeman
  • One Timeguard timer

Lead pot burners firing towards main furnace.

  • Flue to be on LHS of lead pot looking towards the main furnace.
  • Supply a detachable burner cover.
  • Side channel air fan to be on LHS of lead pot looking towards the main furnace.
  • Supply protective cover for air fan and valves
  • The burners will be mounted one each side of the bath to fire down its length and return up under the centre of the bath and exist via flue in the base at the burner end, A time clock is fitted for automatic start up,
  • The BCU flame failure units will pre purge the furnace before light up, this unit can also control lead cooling.
  •

pdf icon Print / Download Furnace Services Limited Lead melting pot - gas fired Datasheet

Additional files

Gas fired lead bath electrical drawing

Gas fired lead bath electrical drawing - Burners

Gas fired lead bath electrical drawing - Alarms

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
