Tektronix TDS 2024B digital storage oscilloscope

Direct From Site Clearance

Direct Site Clearance Price [?]
£ 1,325 (+ VAT)
Clearance ends
23 August 2017 14:00 GMT while stocks last
Buyer's Premium [?]
15% BP will be added to your invoice
Part of a Direct Site Clearance
Electronic Test Equipment
Stock No
NAB922
New or Used
Used (Second Hand)
Location
Our Central Warehouse, Aldridge, UK

Description

Tektronix TDS2000B  Series digital storage oscilloscopes were introduced to enable users to achieve more in less time. Features incorporated as standard include USB connectivity, 16 automated measurements, limit testing, data logging and context-sensitive help.

  1. Compatible probes include: passive, TPP0101 ( 715-8733 ) TPP0201 ( 715-8743 ) P2220 ( 481-0823 ) P6101B ( 796-6708 ) P6015A ( 796-6702 ) P5100A ( 734-5013 );
  2. high voltage differential, P5200A ( 734-5029 );
  3. current, P6021A ( 781-0813 ) A621 ( 851-218 ) A622 ( 851-224 ) and current probe amplifiers TCPA300 ( 764-4391 ) TCPA400 ( 499-627 ).

Features

  • 2.5 k point record length on all channels
  • Advanced triggers including Pulse Width trigger and line-selectable Video trigger
  • 16 automated measurements, and FFT analysis for simplified waveform analysis
  • Built-in waveform limit testing
  • Automated, extended data-logging feature
  • Autoset and signal auto-ranging
  • USB 2.0 Host Port on front panel for data storage, printing, and connecting a USB keyboard
  • USB 2.0 Device Port on rear panel for connection to PC or direct printing to a PictBridge®-compatible printer
  • Built-in context-sensitive Help
  • Probe check Wizard
  • Multiple-language user interface
  • 5.7in. (144 mm) Active TFT colour display
  • Small footprint and lightweight: 4.9in. (124mm) deep and 4.4lb. (2kg)

TDS2000B  Series

  • General purpose digital oscilloscopes for digital design and debug, education and training, manufacturing test and quality control, service and repair,
  • Full sample rate and full record length on all channels for accurate acquisition, all the time,
  • Highly portable, lightweight and compact form factor frees up valuable desk space ,Convenient removable data storage via front panel USB flash drive port ,
  • Plug-and-play PC connectivity via back panel USB device port,OpenChoice™ and NI SignalExpress PC software are supplied for easy documentation and analysis of results,
  • Easy user interface with familiar, analogue-style controls, multipurpose knob, context-sensitive
  • HELP and AUTORANGE function,
  • AUTOSET button to detect and display the waveform, provides different views and displays up to four automatic measurements ,
  • Pulse width trigger speeds digital troubleshooting ,
  • External trigger input ,
  • Probe Check Wizard to quickly verify probes are calibrated and operating properly,
  • Line-selectable video trigger permits triggering on a specific line of video to improve measurement productivity ,
  • Trigger signal frequency readout allows the measurement of a signal's frequency without the need for an output channel ,
  • 11 automatic measurements for fast, error-free measurements, ideal for repetitive tests ,
  • Fast Fourier Transform (FFT) (spectrum) display to analyse, characterise and troubleshoot circuits by viewing frequency and signal strength ,
  • Directly print screen images to any PictBridge compatible printer,
  • Integrated security loop for theft protection
Record Length2.5K points
Trigger typeEdge (rise, fall), video, pulse width, glitch
Trigger modesAuto, normal, single
Glitch Capture12ns
Vertical sensitivity2mv to 5v/div with calibrated fine adjustment
Vertical resolution/accuracy8-bits / ±3%
Timebase range5ns to 50 sec/div
Timebase accuracy50ppm
Input impedance1MΩ in parallel with 20pF
Acquistion modesPeak detect, sample, average, single
Dimensions/weightW. 323.8 H.151.4 d.124.5 Wt 2kg



 Number of Channels4
 Bandwidth200MHz
 Oscilloscope TypeDigital Storage
 SeriesTDS2000C
 CalibratedRSCAL
 Power SourceMains
 Display TypeColour
 Minimum Vertical Sensitivity2mV/div
 Maximum Vertical Sensitivity5V/div
 Minimum Time Base2.5ns/div
 Maximum Time Base50s/div
 Screen Size5.7in
 Sample Rate Random2 Gsps
 Width124.2mm
 Plug TypeType C - European Plug, Type G - British 3-pin, Type J - Swiss 3-pin
 Maximum Operating Temperature+50°C
 Safety Category LevelCAT II
 Dimensions326.3 x 124.2 x 158mm
 Model Number pTDS2024C
 Height158mm
 Safety Category Voltage300V
 Weight2kg
 Rise Time2.1ns
 Safety CategoryCAT II 300 V
 USB InterfaceYes
 Record Length2.5k points/ch
 Minimum Operating Temperature0°C
 Vertical Resolution8 bit
 Length326.3mm



Current NEW Price £2,650.00

pdf icon Print / Download Tektronix TDS 2024B digital storage oscilloscope Datasheet

Photographs taken prior refurbishment. Our refurbishment service is not available on all machines.
